[1] basic design elements
YYMT-IV automatic mold labeling machine is a mature technology based on automatic labeling machine in the original model through the improved design of new models complete, compared with the original model, the models are more convenient, more stable operation. This system uses high performance PLC, touch screen, make the system run more stable, the operation is more simple. Its characteristics are as follows:
I. open program design to make it more adaptable, can be used with more models of blow molding machine equipment;
Ii. this machine uses the touch screen, the operation language is optional;
III. operation is more simple, any location to stop, can further improve the labeling efficiency;
IV. this machine uses the Japanese SMC advanced high power vacuum technology, makes the movement more reliable stable;
V. servo drive system, according to the need to set the speed, so that the work is more stable and reliable, and further improve the labeling speed;
Vi. system uses imported brands of electrical parts;
Vii. system working state and all the input and output information directly displayed on the screen, to determine the inspection is more convenient;
Viii. has perfect protection function, and can carry on many kinds of function setting;
IX. this machine has the perfect procedure self diagnosis system.
Standard Specification for [2] design compliance
Serial number
Standard number
Name
One
GB9061-85
Machinery manufacturing
Two
GB7932-87
Pneumatic system
Three
GB5226-95
electric control system
Four
GBZ1-2002
Hygienic standard for design of industrial enterprises
2 GB7932-87 pneumatic system
3 GB5226-95 electrical control system
4 GBZ1-2002 industrial enterprise design health standards
Main technical parameters
Appearance size: 1600mm * 750mm * 1550mm * a
B) main stroke: X axis 1100mm
C) maximum speed: X axis 60000mm/min
Control axis number: X axis automatic control, automatic control of Z axis, Y axis can be mechanically adjusted
E () open arm suction cup width: 517mm (adjustable)
(f) - 175mm (adjustable)
Height adjustment: 200mm): G
Work efficiency: H completion time < 2S
I) total power: 1KW
J) power supply: single phase 50Hz 220VAC voltage fluctuation range: + 10%
K) equipment comes with power supply voltage regulator.
Main equipment configuration
Model
project
brand
YYMT-IV
PLC
MITSUBISHI Japan
Touch screen
EVIEW
Spindle motor
Japan Fuji AC servo
Countershaft motor
Japan Fuji AC servo
Guide
Taiwan on silver /TBI
Screw
Taiwan on silver /TBI
Proximity switch
Omron
Vacuum device
Japan SMC
Pneumatic parts
AirTAC
Toljan cable
Germany's blue and soft
Equipment installation, commissioning and after sales maintenance
1) installation and adjustment of equipment
We are responsible for the installation and commissioning of the equipment, with the user to provide samples to carry out the test.
2) maintenance of equipment
A) training
We are responsible for the technical training of users, including the user to conduct a detailed operation, general maintenance, troubleshooting, and a series of professional training. Make the correct operation and use of all equipment and can carry out common troubleshooting, and provide the system operation and maintenance manuals and equipment manuals.
B) after sales service: good faith service system
"In good faith service for development", the company of "integrity first, customer first" business philosophy, customer service work referred to a new strategic height, specially put forward the integrity of the service system, the unity of thinking, attention, full investment, full service ", the company launched the first full service customer service system in the whole industry," Shouwenfuze system ", the company received the first customer service requirements of the staff responsible for the needs of users will put in place, anyone with any excuse refused to dodge. Let the company each employee is devoted to customer service, treasure the company's brand and reputation, the quality of civilization service throughout the enterprise's pre-sale, sale, after-sales service in the whole process of the whole process.
Service response time
After receiving the customer service requirements, service response time: the response time for technical support is 10 minutes, according to the situation within 24 hours to reach the scene and troubleshooting.
Notification and response mode:
Users can use telephone, fax, letters and other means to inform our company, I am the first accountability system, the first to receive the service requested by the staff responsible for coordination, arrangements for the implementation of the place and make a record.
Site service
The company has a high-quality, high level of professional and technical team to support the work of after sales service. After receiving instructions to the fastest speed to reach the user site for technical diagnosis, responsible for troubleshooting. Site service time to the user needs, can be done at any time the user needs to conduct on-site service (not more than the work time).
Customer file management
In addition to providing customers with complete technical information, but also for the customer to save the company and customer contact all the business, technical information, free of charge to the user when the user needs.
Acceptance and periodic return
Company to accept user complaints, in a working day to deal with comments and inform users. The company, the company's engineering department to use regular technical support to visit the system, listen carefully to the views of users, it is recommended to provide a complete technical support, and fully guarantee the normal use of the user equipment. Timely collect user comments, suggestions, the user opinion as an important assessment of the company's staff work, service quality, market reputation.
C) maintenance
1, the quality of equipment within the warranty period, the fault caused by equipment design and quality to provide free maintenance, other reasons for non design quality maintenance charge fee.
2, provide the random vulnerable parts, and provide
